HOSE LINES

AREAS OF APPLICATION

Block distributors, vent heating elements of the ultra series, module heating elements

as well as transition pieces and bends are connected with

highly flexible non-insulated or insulated air-lab hose line segments.

PRODUCT DESCRIPTION

Hose line thermo

Hose line

HOSE LINE (SL)

The air-lab hose line is smooth on the interior.

The transitions from the coupling to the nipple are also smooth.

A high level of impermeability and ease of assembly are provided by the air-lab coupling technology with sealing element and bayonet mount. No tools need to be used for coupling

The connection point lock exhibits no torsion, meaning there is no return torque, which might otherwise lead to a loosening of the connection points.

The hose line consists of an ether-polyurethane mantle with an embedded

hard-PVC spiral.

Nipple, coupling and bayonet ring are made from highly resistant,

fiber-reinforced polyamide.

Hygiene plugs protect the hose line from contamination.

The plugs are removed just before assembly.

Hygiene plugs

i

Bayonet nipple

i

Bayonet coupling

i

HOSE LINE THERMO (SLT)

The air-lab hose line thermo is made in the same way as the previously named non-insulated air-lab hose line. However, it also has an additional insulating tube lining.

The insulating tube lining consists of a highly flexible foam of synthetic rubber with an extremely low thermal conductivity.

Hygiene plugs

i

Bayonet nipple

i

Bayonet coupling

i

Insulation

i

TECHNICAL DATA

Type

Unit

SL72/80-500

article no. 70265

SL72/80-750

article no. 70266

SL72/80-1000

article no. 70267

SL72/80-2000

article no. 70268

Length

Length when bulged

Bend radius (min.)

Diameter (interior)

Diameter (exterior)

Diameter (bayonet)

Air tightness

Operational temperature

Fire index number

Thermal conductivity (at 20°C)

Microbe resistant

mm

x d

mm

Pa

°C

W/mK

500

280

1,5

72,5

80,0

97,8

D-100/+100

STL-25/STH+100

5.2 (fire

retardant)

0,194

Ja

750

440

1,5

72,5

80,0

97,8

D-100/+100

STL-25/STH+100

5.2 (fire

retardant)

0,194

Ja

2.000

1.250

1,5

72,5

80,0

97,8

D-100/+100

STL-25/STH+100

5.2 (fire

retardant)

0,194

Ja

1.000

600

1,5

72,5

80,0

97,8

D-100/+100

STL-25/STH+100

5.2 (fire

retardant)

0,194

Ja

Type

Unit

SLT72/80-500

article no. 70269

SLT72/80-750

article no. 70270

SLT72/80-1000

article no. 70271

SLT72/80-2000

article no. 70272

Length

Length when bulged

Bend radius (min.)

Diameter (interior)

Diameter (exterior)

Diameter (bayonet)

Air tightness

Operational temperature

Fire index number

Thermal conductivity (at 20°C)

Microbe resistant

mm

x d

mm

Pa

°C

W/mK

500

300

1,5

72,5

106,0

97,8

D-100/+100

STL-25/STH+100

5.2 (fire

retardant)

0,036

Ja

750

470

1,5

72,5

106,0

97,8

D-100/+100

STL-25/STH+100

5.2 (fire

retardant)

0,036

Ja

2.000

1.350

1,5

72,5

106,0

97,8

D-100/+100

STL-25/STH+100

5.2 (fire

retardant))

0,036

Ja

1.000

650

1,5

72,5

106,0

97,8

D-100/+100

STL-25/STH+100

5.2 (fire

retardant)

0,036

Ja

ACCESSORIES

● air-lab vent heating elements ultra

● air-lab block distributor

● air-lab bends

● air-lab transition pieces

● air-lab hose line holder (article no. 70194)
