WALL DUCTS

Weather protection grill

Connection sleeve

Sleeve

Connection sleeve with collar

Flange reduction sleeve

AREAS OF APPLICATION

The wall duct is for fresh and outgoing air flow through solid or system walls and ceilings.

Almost any duct thickness is feasible because of its modular construction and the variability

allowed in the module insertion depth.

The modules are connected during assembly using a suitable adhesive.

FLANGE REDUCTION SLEEVE

The flange reduction sleeve is for connecting to air pipes in the inside of the building.

Connecting side 1 to insert in a connecting sleeve with collar

i

Drill holes for wall mounting with screws

i

Condensation drain

The connecting pieces can be connected via a tube to a drain.

If this is not required, a plug is used.

i

Surrounding groove for accommodating insulation in the connecting pipe (minimization of thermal bridging)

i

CONNECTION SLEEVE WITH COLLAR

The connector sleeve serves to connect the sleeve with the flange reduction sleeve.

Connection side 2 for accommodating a flange reduction sleeve

i

The collar is for connecting to a damp-proof covering

i

Connecting side 1
to insert in
a sleeve

i

SLEEVE

The function of the sleeve is to accommodate (connect) two connecting sleeves (with or without collar).

Connection side 2 for accommodating a connecting sleeve with or without collar

i

Connection side 2 for accommodating a connecting sleeve with or without collar

i

CONNECTION SLEEVE

The connecting sleeve extends the desired wall duct thickness.

An unlimited wall duct thickness can be accommodated.

Connecting side 1 to insert in a sleeve or another connecting sleeve

i

Connecting side 2 to accommodate a weather protection grill or another connecting sleeve

i

WEATHER PROTECTION GRILL

The weather protection grill guarantees a minimal loss in pressure due to the large free areas and fluid streamlined rib design.

Supporting edge and spigot length are generously sized for sufficient coverage of the plaster surface and the insertion depth

i

Draining edge overhang

i

PRODUCT VARIATIONS

Weather protection grill 250

Connection sleeve 250

Sleeve 250

Connection sleeve with collar 250

Flange reduction sleeve 250-160

Flange reduction sleeve 250-200

Basis Set 250

article no. 70279

●

Connection sleeve 250

article no. 10326

●

Wall connection

Set 250-160

article no. 70282

●

Wall connection

Set 250-200

article no. 70283

●

TECHNICAL DATA

Penetration strength

Combination of:
● Connection sleeve with collar
● Sleeve

Combination of:

● Connection sleeve with collar
● Sleeve

● Connection sleeve

Combination of:
● Connection sleeve with collar
● Sleeve

● Connection sleeve

* Extension using every other connecting sleeve

Basis Set 250

article no. 70279

200…252

280…367

Connection sleeve 250

article no. 10326

367…482*

1…115

Wall connection

Set 250-160

article no. 70282

Wall connection

Set 250-200

article no. 70283

Unit

mm

Diameter

Component (connection internal diameter)

Built-in connection

line

Condensation drain

mm

251

160

15

200

15

ACCESSORIES

● Pressure hose for condensation drain (article no. 10437)

● Source welding adhesive (article no. 10340)
